Part Number: XNSPF069MP

Description: RS-R Sports-I Club Racer Coilover

Details:

Part#:XNSPF069MP
Compatibility: 2022+ Subaru BR-Z
Chassis code: ZD8

Preset Approximate Height From RS-R: Automatic
Front -15mm to -20mm (-0.6in to -0.8in)
Rear -15mm to -20mm (-0.6in to -0.8in)

Maximum Adjustment Range: Automatic
Front +15mm to -75mm (+0.6in to -3.0in)
Rear +35mm to -60mm (+1.4in to -2.4in)

Recommended Adjustments for Optimal Ride-ability: Automatic
Front +5mm to -40mm (+0.2in to -1.6in)
Rear +5mm to -40mm (+0.2in to -1.6in)

Preset Approximate Height From RS-R: 6 Speed Manual
Front -15mm to -20mm (-0.6in to -0.8in)
Rear -20mm to -25mm (-0.8in to -1.0in)

Maximum Adjustment Range: 6 Speed Manual
Front +15mm to -75mm (+0.6in to -3.0in)
Rear +35mm to -65mm (+1.4in to -2.6in)

Recommended Adjustments for Optimal Ride-ability: 6 Speed Manual
Front +5mm to -40mm (+0.2in to -1.6in)
Rear +5mm to -45mm (+0.2in to -1.8in)

Spring Rates:
Front 9.00kg/mm
Rear 10.0kg/mm
